AC IN-LINE ELECTROMAGNETS

electromagnetBuilt in AC to DC converter.

(Just connect to 110V. AC line.)

Can be splicedd to longer cable for system integration.

Suitable for holding and clamping applications.

Continuous duty cycle.

Max. Ambient temp. 40°C (100°F)

 110 Volts AC In-line Round Electromagnets:

Part Number

Holding Value

Diameter

Height

Mounting Thread

Thread Depth

Lead Length

Watts

Amps

Net Weight

List Price

110 V. AC

0" Gap

A

B

C

D

INLINE-12C

40 lbs.

1-1/4”

1-1/4”

1/4-20

3/8”

72” cable

2.8

0.03

1 lb.

$156

INLINE-17C

110 lbs.

1-3/4”

1-5/8”

1/4-20

1/2”

72” cable

3.6

0.03

1.3 lbs.

$174

INLINE-2016

180 lbs.

2”

1-5/8”

1/4-20

1/2”

36” cable

5.6

0.05

1.1 lbs.

$183

INLINE-2025

200 lbs.

2”

2-1/2”

1/4-20

3/4”

36” cable

13

0.12

2 lbs.

$191

INLINE-3030

400 lbs.

3”

3”

5/16-18

1”

36” cable

25

0.23

5 lbs.

$236

INLINE-4030

700 lbs.

4”

3”

3/8-16

1”

36” cable

36

0.33

9 lbs.

$291

INLINE-5030

1200 lbs.

5”

3”

1/2-13

1”

36” cable

43

0.39

13 lbs.

$353

INLINE-6030

1700 lbs.

6”

3”

5/8-11

1”

36” cable

46

0.42

20 lbs.

$453


110 Volts AC In-line Rectangular & Square Electromagnets:

Part Number

Holding Value

Width

Length

Height

Hole Spacing

Mounting Thread

Thread Depth

Lead Length

Watts

Amps

Net Weight

List Price

110 V. AC

0" Gap

A

B

C

D

E

F

INLINE-251512

160 lbs.

1-1/2”

2-1/2”

1-1/4”

1”

10-32

3/8”

36” cable

10

0.09

1 lb.

$182

INLINE-25C

280 lbs.

2-1/2”

2-1/2”

1-1/2”

3/4”

1/4-20

1/2”

72” cable

8.2

0.08

2.5 lbs.

$198

INLINE-252515

300 lbs.

2-1/2”

2-1/2”

1-1/2”

N/A

1/4-20

1/2”

36” cable

14

0.13

2 lbs.

$198

INLINE-452518

600 lbs.

2-1/2”

4-1/2”

1-7/8”

2”

1/4-20

3/4”

36” cable

29

0.26

5 lbs.

$310

INLINE-353520

700 lbs.

3-1/2”

3-1/2”

2”

N/A

3/8-16

3/4”

36” cable

28

0.25

5 lbs.

$326

INLINE-603020

900 lbs.

3”

6”

2”

3”

3/8-16

1”

36” cable

33

0.3

8 lbs.

$364

INLINE-804025

1700 lbs.

4"

8”

2-1/2”

4”

3/8-16

1”

36” cable

58

0.53

18 lbs.

$453


220 Volts AC In-line Round Electromagnets:

Part Number

Holding Value

Diameter

Height

Mounting Thread

Thread Depth

Lead Length

Watts

Amps

Net Weight

List Price



220 V. AC

0" Gap

A

B

C

D

INLINE-2016-220

180 lbs.

2”

1-5/8”

1/4-20

1/2”

36” cable

5.6

0.03

1.1 lbs.

$220


220 Volts AC In-line Rectangular & Square Electromagnets:

Part Number

Holding Value

Width

Length

Height

Hole Spacing

Mounting Thread

Thread Depth

Lead Length

Watts

Amps

Net Weight

List Price



220 V. AC

0" Gap

A

B

C

D

E

F



INLINE-252515-220

300 lbs.

2-1/2”

2-1/2”

1-1/2”

N/A

1/4-20

1/2”

36” cable

14

0.13

2 lb.

$238



Safety Caution:

The holding values as listed are actual readings of breaking away a 1/2" steel plate with no air-gaps between them. They have not been de-rated. For safety in holding applications, do not use electromagnets at more than 1/2 of rated value. In lifting applications, do not use at more than 1/4 of rated value. Do not use electromagnets over people.
