DC ROUND ELECTROMAGNETS
Radial pole, flat surface.
Best in holding
applications.
Maximum holding at no
gap.
Continuous duty
cycle.
Max.
Ambient temp 40°C (100°F)
12 Volts DC Round Electromagnets:
|
Part Number |
Holding Value |
Diameter |
Height |
Mounting Thread |
Thread Depth |
Lead Length |
Watts |
Amps |
Net Weight |
List Price |
|
|
12 V. DC |
0" gap |
A |
B |
C |
D |
|
|
|
|
International Shipping? | |
|
R-0515-12 |
3 lbs. |
1/2” |
1-1/2” |
6-32 |
3/8” |
24” leads |
1.4 |
0.12 |
1.8 oz. |
$70 |
|
|
R-0707-12 |
6 lbs. |
3/4” |
3/4” |
10-32 |
1/4” |
24” leads |
0.7 |
0.06 |
1.5 oz. |
$47 |
|
|
R-0712-12 |
9 lbs. |
3/4” |
1-1/4” |
10-32 |
3/8” |
24” leads |
1.4 |
0.12 |
2.1 oz. |
$47 |
|
|
R-1007-12 |
26 lbs. |
1” |
3/4” |
10-32 |
1/4” |
24” leads |
1.4 |
0.12 |
2.3 oz. |
$47 |
|
|
R-1012-12 |
32 lbs. |
1” |
1-1/4” |
10-32 |
3/8” |
24” leads |
3.6 |
0.3 |
3.3 oz. |
$56 |
|
|
R-1207-12 |
45 lbs. |
1-1/4” |
3/4” |
1/4-20 |
1/4” |
24” leads |
3.3 |
0.28 |
3.8 oz. |
$62 |
|
|
R-1212-12 |
50 lbs. |
1-1/4” |
1-1/4” |
1/4-20 |
3/8” |
24” leads |
4.4 |
0.37 |
5.7 oz. |
$64 |
|
|
R-1515-12 |
80 lbs. |
1-1/2” |
1-1/2” |
1/4-20 |
1/2” |
24”
leads |
4.6 |
0.38 |
9.9 oz. |
$78 |
|
|
R-1716-12 |
130 lbs. |
1-3/4” |
1-5/8” |
1/4-20 |
1/2” |
24” leads |
8.5 |
0.71 |
14 oz. |
$84 |
|
|
R-2016-12 |
180 lbs. |
2” |
1-5/8” |
1/4-20 |
1/2” |
24” leads |
5.6 |
0.47 |
1.2 lbs. |
$87 |
|
|
R-2025-12 |
200 lbs. |
2” |
2-1/2” |
1/4-20 |
3/4” |
24” leads |
13 |
1.1 |
2 lbs. |
$126 |
|
|
R-3030-12 |
400 lbs. |
3” |
3” |
5/16-18 |
1” |
36” cable |
25 |
2.1 |
5 lbs. |
$229 |
|
|
R-4030-12 |
700 lbs. |
4” |
3” |
3/8-16 |
1” |
36” cable |
31 |
3.0 |
9 lbs. |
$314 |
|
|
R-5030-12 |
1200 lbs. |
5” |
3” |
1/2-13 |
1” |
36” cable |
43 |
3.6 |
13 lbs. |
$350 |
SOLD OUT |
|
R-6030-12 |
1700 lbs. |
6” |
3” |
5/8-11 |
1” |
36” cable |
46 |
3.8 |
20 lbs. |
$491 |
24 Volts DC Round Electromagnets:
|
Part Number |
Holding Value |
Diameter |
Height |
Mounting Thread |
Thread Depth |
Lead Length |
Watts |
Amps |
Net Weight |
List Price |
|
|
24 V. DC |
0" gap |
A |
B |
C |
D |
|
|
|
|
International Shipping? | |
|
R-0515-24 |
3 lbs. |
1/2” |
1-1/2” |
6-32 |
3/8” |
24”
leads |
1.4 |
0.06 |
1.8 oz. |
$70 |
|
|
R-0707-24 |
6 lbs. |
3/4” |
3/4” |
10-32 |
1/4” |
24” leads |
0.7 |
0.03 |
1.5 oz. |
$47 |
|
|
R-1007-24 |
26 lbs. |
1” |
3/4” |
10-32 |
1/4” |
24”
leads |
1.4 |
0.06 |
2.3 oz. |
$47 |
|
|
R-1012-24 |
32 lbs. |
1” |
1-1/4” |
10-32 |
3/8” |
24”
leads |
3.6 |
0.15 |
3.3 oz. |
$56 |
|
|
R-1207-24 |
45 lbs. |
1-1/4” |
3/4” |
1/4-20 |
1/4” |
24”
leads |
3.3 |
0.14 |
3.8 oz. |
$62 |
|
|
R-1212-24 |
50 lbs. |
1-1/4” |
1-1/4” |
1/4-20 |
3/8” |
24”
leads |
4.4 |
0.18 |
5.7 oz. |
$64 |
|
|
R-1515-24 |
80 lbs. |
1-1/2” |
1-1/2” |
1/4-20 |
1/2” |
24”
leads |
4.6 |
0.19 |
9.9 oz. |
$78 |
|
|
R-1716-24 |
130 lbs. |
1-3/4” |
1-5/8” |
1/4-20 |
1/2” |
24”
leads |
8.5 |
0.36 |
14 oz. |
$84 |
|
|
R-2016-24 |
180 lbs. |
2” |
1-5/8” |
1/4-20 |
1/2” |
24”
leads |
5.6 |
0.23 |
1.2 lbs. |
$87 |
|
|
R-2025-24 |
200 lbs. |
2” |
2-1/2” |
1/4-20 |
3/4” |
24”
leads |
13 |
0.54 |
2 lbs. |
$126 |
|
|
R-3030-24 |
400 lbs. |
3” |
3” |
5/16-18 |
1” |
36”
cable |
25 |
1.0 |
5 lbs. |
$229 |
|
|
R-4030-24 |
700 lbs. |
4” |
3” |
3/8-16 |
1” |
36”
cable |
31 |
1.5 |
9 lbs. |
$314 |
|
|
R-5030-24 |
1200 lbs. |
5” |
3” |
1/2-13 |
1” |
36”
cable |
43 |
1.8 |
13 lbs. |
$350 |
|
|
R-6030-24 |
1700 lbs. |
6” |
3” |
5/8-11 |
1” |
36”
cable |
46 |
1.9 |
20 lbs. |
$491 |
110 Volts DC Round Electromagnets:
|
Part Number |
Holding Value |
Diameter |
Height |
Mounting Thread |
Thread Depth |
Lead Length |
Watts |
Amps |
Net Weight |
List Price |
|
|
110 V. DC |
0" gap |
A |
B |
C |
D |
|
|
|
|
International Shipping? | |
|
R-1212-110 |
40 lbs. |
1-1/4” |
1-1/4” |
1/4-20 |
3/8” |
72” cable |
2.8 |
0.03 |
1 lb. |
$103 |
|
|
R-1716-110 |
110 lbs. |
1-3/4” |
1-5/8” |
1/4-20 |
1/2” |
72” cable |
3.6 |
0.03 |
1.2 lbs. |
$110 |
|
|
R-2016-110 |
180 lbs. |
2” |
1-5/8” |
1/4-20 |
1/2” |
36”
cable |
5.6 |
0.05 |
1.3 lbs. |
$112 |
|
|
R-2025-110 |
200 lbs. |
2” |
2-1/2” |
1/4-20 |
3/4” |
36”
cable |
13 |
0.12 |
2 lbs. |
$174 |
|
|
R-3030-110 |
400 lbs. |
3” |
3” |
5/16-18 |
1” |
36”
cable |
25 |
0.23 |
5 lbs. |
$289 |
|
|
R-4030-110 |
900 lbs. |
4” |
3” |
3/8-16 |
1” |
36”
cable |
31 |
0.30 |
9 lbs. |
$350 |
SOUL OUT |
|
R-5030-110 |
1200 lbs. |
5” |
3” |
1/2-13 |
1” |
36” cable |
43 |
0.39 |
13 lbs. |
$424 |
|
|
R-6030-110 |
1700 lbs. |
6” |
3” |
5/8-11 |
1” |
36” cable |
46 |
0.42 |
20 lbs. |
$536 |
Dimensional Drawing:
Safety Caution:
The holding values as listed are actual readings of breaking away a 1/2" steel plate with no air-gaps between them. They have not been de-rated. For safety in holding applications, do not use electromagnets at more than 1/2 of rated value. In lifting applications, do not use at more than 1/4 of rated value. Do not use electromagnets over people.
